MP500 is a robust potentiometer.
The sensor provides an analogue voltage output, radiometric, with amplitude of 0..5Vdc or 0.5 to 4.5 Vdc proportional to the shaft angle position. The scanning principle of the sensor is based on a magnetic scanning principle. The encoder comes with sturdy enlarged bearings and mechanical locking. This ensures a long durability.
The potentiometer is powered by a 5Vdc supply and available with an axial cable outlet. The length of the cable may be decided upon order. The sensor is only 30 millimeter in diameter making it useful in space limited applications.
The active angle of the sensor, e.g. the area in which the full scale (0..5Vdc) is displayed is configurable upon order. This means that the full scale can be provided from 20º to 360º based on the requirements of the application.
SUITABLE APPLICATIONS
| Antal kanaler | 1 channel |
|---|---|
| Elektrisk anslutning | Cable |
| Elektriskt gränssnitt | Analogue voltage |
| Flänstyp | Synchro flange |
| Funktion | Potentiometer |
| Matningsspänning | 9-30 Vdc, 5 Vdc |
| Ytterdiameter | ø30 mm |
| Ytbehandling | Anodized aluminium |
| Shock | 200g |
| Vibration | 50g 20-2000Hz |
| Temperaturområde | -40° till +70°C |
